model:HDL-MIRL01.01

SB-IR-Learn.01 is the Infrared Code learner. It can learn various key commands. For example, you want to control the AC, TV, DVD, Audio & Video Device, etc. IR learner can be learned into HDL BUSPRO Pro system. It has the testing mode and it do not need the extra driver.

IR Learner
IR Learner
IR Learner
IR Learner

SB-IR-Learn.01 is the Infrared Code learner. It can learn various key commands. For example, you want to control the AC, TV, DVD, Audio & Video Device, etc. IR learner can be learned into HDL BUSPRO Pro system. It has the testing mode and it do not need the extra driver.



■ USB Interface, no driver and easy to use

■ Infrared Code learning

■ Infrared Code sending test

■ Indicator will flash when the device is learning the IR Code

Electrical Parameter:
Range of carrier wave frequency 38KHz±20%
USB 2.0, no need driver


Environmental Condition:
Working temperature  -5℃~45℃
Working relative humidity Up to 90%
Storage temperature  -20℃~+60℃

Storage relative humidity  Up to 93%


Approved
CE

RoHS


Product Information:
Dimensions 98×70×38(mm)
Weight 179.7g
Housing material ABS

Installation USB 2.0 interface

Protection degree  IP20
