Light control: switch, dimming, color temperature and RGB

Curtain control: supports curtain opening, closing, stopping, and percentage control

Scene control: supports one click scene control

Built in temperature sensor: supports sending local temperature values to the bus, used for inputting scene and

automation control conditions

RGB LED indicator function: supports custom button indicator light brightness and color configuration

Button locking function: Supports panel button locking function to prevent external personnel from manually controlling

the panel or children from accidentally touching it

Proximity detection: Once the sensor detects near human motion, the touch screen automatically wakes up.

Button text laser engraving customization: supports custom button laser engraving, which can engrave text size and

content according to user needs, making it easy to identify the target controlled by the corresponding button

Dimensions (W X H X D) 86×86×8.1/12.1(mm)

Net weight 77.6g

Housing material Aluminum alloy

Installation Wall box (See Figure 6)

IP degree (compliant with EN 60529) IP20
